V-RAPTOR XL 8K S35 Production Pack (V-Lock)

RED DIGITAL CINEMA

V-RAPTOR XL 8K S35 Production Pack (V-Lock)

RED-9156・MFR#710-0382

価格には諸経費5万円(税抜)を含んでいます。前払い(事前銀行振込)頂きますと本体価格から7％OFFになります。

2022年9月19日(月・祝) 10時〜 9月26日(月) 23時59分まで

通常価格￥（税抜）を、数量限定価格にて販売

なくなり次第、販売終了となります。

こちらは、B-Stock商品 です。

2022年9月19日(月・祝) 10時〜 9月26日(月) 23時59分まで

通常価格￥（税抜）を、数量限定価格にて販売

なくなり次第、販売終了となります。

￥7,702,200

(税抜￥7,002,000 )

数量

カートに入れる

お問い合わせ

『RED V-RAPTOR』に関するお問合わせ

Rental How to register
レンタルご利用について

商品の納期について

※弊社取り扱いの製品は、製品確認のため一度開梱されています。

※ご購入の前に「shop@raid-japan.co.jp」が受信可能かどうかの確認をお願い致します。
　お買い物後に購入内容や支払い方法、発送案内等の重要なお知らせをメールにて送信しております。

V-RAPTOR XL 8K S35 Production Pack (V-Lock)についてつぶやく

V-RAPTOR XL 8K S35 Production Pack (V-Lock)

▼ DETAIL を見る

PRODUCT CONFIGURATION

V-RAPTOR^™XL 8K S35

1 x V-RAPTOR™ XL 8K Camera System
1 x DSMC3 RED Touch 7” LCD
1 x DSMC3 RED Touch 7.0" LCD Hood
1 x DSMC3 RMI Cable 18"
2 x RED PRO CFexpress 2TB
1 x RED CFexpress Card Reader
4 x REDVOLT XL-V
1 x RED Compact Dual V-Lock Charger
1 x DSMC3 RED 5-Pin to Dual XLR Adapter
1 x V-RAPTOR XL Top Handle w/ Extensions
1 x V-RAPTOR XL Top 15mm LWS Rod Support Bracket
1 x V-RAPTOR XL Bottom 15mm LWS Rod Support Bracket
1 x V-RAPTOR XL Riser Plate
2 Year Standard Warranty (camera only)
For Accessory Warranty information, please visit Terms and Conditions of Sale

DETAIL

仕様

V-RAPTOR XL 8K S35

SENSOR SPECS
SENSOR	V-RAPTOR™ 8K S35 35.4 Megapixel CMOS
EFFECTIVE PIXELS	8192 x 4320
SENSOR SIZE	40.96 mm x 21.60 mm (Diagonal: 46.31 mm)
DYNAMIC RANGE	17+ stops
KEY FEATURES
BUILT-IN ND	Motorized clear filter and precision controlled electronic ND filter Electronic ND minimum density 2 stops, maximum density 7 stops Electronic ND selectable increments of 1/3 stops, 1/4 stops, and 1 stop
MOUNT TYPE	Interchangeable Lens Mount, Included V-RAPTOR XL PL Mount (Shimmable) Optional V-RAPTOR XL Locking Canon EF Mount Physically compatible with DSMC Lens Mounts, but does not provide electronic communication or control
BATTERY TYPE	Integrated Dual Voltage 14/26 V V-Lock battery interface
RECORDING
MAX DATA RATES	Up to 800 MB/s using RED branded or other qualified CFexpress media cards[1]
REDCODE® RAW MAX FRAME RATES	120 fps at 8K 17:9 (8192 x 4320), 150 fps at 8K 2.4:1 (8192 x 3456) 140 fps at 7K 17:9 (7168 x 3780), 175 fps at 7K 2.4:1 (7168 x 3024) 160 fps at 6K 17:9 (6144 x 3240), 200 fps at 6K 2.4:1 (6144 x 2592) 192 fps at 5K 17:9 (5120 x 2700), 240 fps at 5K 2.4:1 (5120 x 2160) 240 fps at 4K 17:9 (4096 x 2160), 300 fps at 4K 2.4:1 (4096 x 1728) 320 fps at 3K 17:9 (3072 x 1620), 400 fps at 3K 2.4:1 (3072 x 1296) 480 fps at 2K 17:9 (2048 x 1080), 600 fps at 2K 2.4:1 (2048 x 864)
PLAYBACK FRAME RATES (PROJECT TIME BASE)	23.98, 24, 25, 29.97, 30, 50, 59.94, 60 fps, all resolutions
BEST AVAILABLE REDCODE® SETTINGS	REDCODE HQ, MQ and LQ at 8K 17:9 (8192 x 4320) up to 60 fps REDCODE LQ at 8K 17:9 (8192 x 4320) up to 120 fps REDCODE HQ, MQ and LQ at 6K 17:9 (6144 x 3240) up to 96 fps REDCODE MQ and LQ at 6K 17:9 (6144 x 3240) up to 160 fps REDCODE HQ, MQ and LQ at 4K 17:9 (4096 x 2160) up to 240 fps REDCODE HQ, MQ and LQ at 2K 17:9 (2048 x 1080) up to 480 fps
REDCODE® RAW ACQUISITION FORMATS	8K 17:9 (8192 x 4320), 2:1, 2.4:1, 16:9, 1:1 and Anamorphic 2x, 1.8x, 1.6x, 1.5x, 1.3x, 1.25x 7K 17:9 (7168 x 3780), 2:1, 2.4:1, 16:9, 1:1 and Anamorphic 2x, 1.8x, 1.6x 6K 17:9 (6144 x 3240), 2:1, 2.4:1, 16:9, 1:1 and Anamorphic 1.5x, 1.3x, 1.25x 5K 17:9 (5120 x 2700), 2:1, 2.4:1, 16:9, 1:1 4K 17:9 (4096 x 2160), 2:1, 2.4:1, 16:9, 1:1 3K 17:9 (3072 x 1620), 2:1, 2.4:1, 16:9, 1:1 2K 17:9 (2048 x 1080), 2:1, 2.4:1, 16:9, 1:1
Apple ProRes	Dedicated recording in ProRes 4444 XQ, ProRes 4444, ProRes 422 HQ, ProRes 422, and ProRes 422 LT at resolutions up to 4K (4096x2160) 120P Proxy recording available up to ProRes 422 HQ in 2K (2048 x 1080) up to 60P
GENERAL
CONSTRUCTION	Aluminum Alloy
WEIGHT	8lbs / 3.65kg (V-Lock with PL Mount) 8.08lbs / 3.66kg (Gold Mount with PL Mount)
DC POWER INPUT	19.5-34 V via 4-pin 2B DC-IN
OPERATING TEMPERATURE	0°C to 40°C (32°F to 104°F)
STORAGE TEMPERATURE	-20°C to 50° C (-4°F to 122°F)
STORAGE RELATIVE HUMIDITY	0% to 85% non-condensing
ADDITIONAL FEATURES
COLOR MANAGEMENT	Image Processing Pipeline 2 (IPP2) Supports 33×33×33 3D LUTs Supports import of CDLs
AUDIO	Integrated dual channel digital mono microphones, uncompressed, 24-bit 48 kHz Integrated dual channel mic/line/+48V input via 5-Pin 00B Audio Port, uncompressed, 24-bit 48 kHz
AUTOFOCUS	Phase Detect and Contrast
REMOTE CONTROL	Wi-Fi for camera control via interchangeable dual band (2.4 GHz/5 GHz) antenna mounted to a female RP-SMA connector Wired control via USB-C (compatible USB-C to Ethernet adapter1 required) or Gigabit Ethernet allowing remote camera control, live MJPEG preview video feed and remote media offload 9-Pin 0B GIG-E (1000BASE-T) 4-Pin 00B CTRL (RS-232)
POWER OUTPUTS²	Regulated 12 V Outputs 2x P-TAP Connectors (3AMP Combined) 1x Rear 2-Pin 0B (3 AMP) 1x Rear 2-Pin 0B (1.5 AMP) 1x Front 2-Pin 0B (1 AMP) Regulated 24 V Connectors 2x Front 3-Pin Fischer (3 AMP Combined)
MONITOR OUTPUTS	Proprietary Top Accessory Port for Monitoring and Control 3x 12G-SDI with 6G-SDI, 3G-SDI and 1.5G-SDI modes (SDI 1/2/3) 1x 3G-SDI with 3G-SDI and 1.5G-SDI modes (EVF) 12G-SDI: Up to 4096 x 2160 4:2:2 for 60p 6G-SDI: Up to 4096 x 2160 4:2:2 for 30p, 25p, 24p 3G-SDI: Up to 2048 x 1080 4:2:2 for 60p 1.5G-SDI: Up to 2048 x 1080 4:2:2 for 30p, 25p, 24p SMPTE Timecode, HANC Metadata, 24-bit 48 kHz Audio
MONITOR OPTIONS	DSMC3™ RED® Touch 7.0” LCD IP streamed 1080p live preview wirelessly or wired via USB-C or Ethernet. Integrated 2.4" LCD for camera control (no preview video)
CAMERA SYNC OPTIONS	Tri-Level Genlock through BNC Linear Timecode (LTC) through 5-Pin 0B PTP through 9-Pin 0B GIG-E Wireless Genlock and Timecode through Integrated Ambient Communication Network (ACN)
SOFTWARE
RED CONTROL	Access full camera controls and live preview from iOS or Android devices. Available from the Apple App Store and Google Play Store. RED Control works wirelessly or wired via USB-C or Ethernet.

Tech specs reflect both current and projected information. Everything is subject to change.

1. For more information on compatible accessories, go to RED.com/third-party-accessories
2. High voltage power source required.

RED®, V-RAPTORTM are trademarks of RED.COM, LLC. All trademarks, trade names, logos, icons, images, and product names are copyrights and/or trademarks of RED.COM, LLC, registered (where applicable) in the U.S. and other countries. All rights reserved. Copyright © 2022 RED.COM, LLC.
